Ship via: Can Ship UPS
Adjustment: Features side to side, depth, height and tilt adjustment for perfect drawer alignment Tool-less integrated height adjustment +3.5 mm (9/64") Tool-less adjustment adapter for side adjustment ±1.5 mm (1/16") and depth adjustment +3 mm (1/8")
Application: Face frame or frameless For 48" wide drawers
Drawer length: (21") 533 mm
Features: For 12.7 - 16 mm (1/2 - 5/8") drawer box
Finish: Zinc-plated
Installation depth: (21 27/32 - 23 17/32") 555 - 598 mm
Load bearing capacity: Per pair: (100 lbs) 45 kg
Material: Steel
Model: F130100729204
Note: Dimensions shown in face frame with rear mounting socket; can also be used in frameless
Suitable for: For 5/8" drawer box
Type of closing: Soft & silent
Type of pull out: Full extension
Version: 3-D
